GB Standard Flanged Sight Glass Equipped With PTFE Seal For Customers
Product Details:
| Place of Origin: | China |
| Brand Name: | CXDLV |
| Model Number: | SG-ZT |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Packaging Details: | Suitable Plywood Cases according to different valves' structure |
| Delivery Time: | 5~60 work days |
| Payment Terms: | T/T, L/C, , D/A, D/P, Western Union, MoneyGram |
|
Detail Information |
|||
| Features: | Bolted Cover, Drain Plug, Blow-out Proof Stem | Gasket: | PTFE |
|---|---|---|---|
| Connection Type: | Flanged | Standard: | GB/ANSI |
| Disc Material: | CF8,CF3,CF8M.. | Seal: | PTFE |
| Pressure: | 0.6Mpa | ||
| Highlight: | PTFE Seal Flanged Sight Glass,GB Standard Flanged Sight Glass,Customers Flanged Sight Glass |
||
Product Description
Product Feature
Double Flange Sight Glass
Applicable Standards:
- Design and Manufacturing: ASTM B16.34
- Flange Connection: ASTI16.5
- Test and Inspection: API598
Size Range:
- 1/2"~8"
Pressure Rating:
- ANSI 300LB
Temperature Range:
- -20°C~185°C
Double Window Sight Glass is a simple assembly of two glasses on single cast or fabricated body at two opposite sides. Use of these types of flow indicator is for spot inspection and view of process parameter.
Salient Features
Easy Maintenance
Available in all most all Material of Construction
Manufactured to the Highest Standard
Durable Construction
Material Test Certificate & Pressure Test Certificates furnished on request.
Technical Data
| Size | Dimension(mm) | ||||||
| H | L | D | D1 | D2 | b | Z-d | |
| 2" | 140 | 230 | 162 | 127 | 92 | 23 | 8-19 |
| 6" | - | 420 | 318 | 270 | 216 | 36.5 | 12-22 |
Package&Delivery
Packing Details: We choose suitable wood cases according to different valves and arrange skilled workers to pack in case of bruise. Long term cooperated forwarder will book space, clear customs and transport for us without delay. There are three ways for transportation, by sea, by air and by train. We will arrange transportation according to customers' needs.
Delivery Details: according to the order, 7~60days
FAQ:
- Q: What is the brand name of this product?
A: The brand name of this product is CXDLV. - Q: What is the model number of this product?
A: The model number of this product is SG-ZT. - Q: Where is this product manufactured?
A: This product is manufactured in China by CXDLV Manufacturing. - Q: What is the material used for the flange and sight glass?
A: The flange and sight glass are made of high-quality stainless steel. - Q: What is the maximum working pressure of this product?
A: The maximum working pressure of this product is 10 bar.
