Stainless Steel 3-Way Ball Valve T-port Flange Ends with Worm Gear
Product Details:
| Place of Origin: | China |
| Brand Name: | CXDLV |
| Certification: | CE&ISO |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | negotiation |
| Packaging Details: | Suitable Plywood Cases according to different valves structure |
| Delivery Time: | 5~25 Work Days |
| Payment Terms: | T/T,Paypal,Western Union,D/A,L/C,D/P,MoneyGram |
| Supply Ability: | 500pcs/Mon |
|
Detail Information |
|||
| Body Material: | CF8,CF8M,WCB,2205,CF3M | Ball Material: | 304/316/316L/304L |
|---|---|---|---|
| Seat Material: | PTFE,PPL | Standard: | GB |
| Design: | Reduced Bore/Full Bore | Actuated: | Integrate ISO 5211 Mounting Pad |
Product Description
Stainless Steel 3-Way Ball Valve T-port Flange Ends with Worm Gear
Application
- 3 way ball valves are ball valves with three ports, instead of the usual two ports. Three way ball valves are suitable for mixing, diverting, selection and shutoff applications. 3 way valves can often take the place of two separate valves, providing a cost effective valve solution. The main types of 3-way ball valves are L-port and T-port.
- A 3 way ball valve is designed with three ports that allow operators to control and redirect the flow direction of liquids or gases. Inside the valve body, a rotating ball with a bore channels the media toward different outlets depending on the handle or actuator position. This configuration enables both diverting and mixing functions, making it more versatile than standard two-way ball valves.
Design Features
- Size:1/2"-8",DN15-DN200
- Material :CF8,CF8M,WCB
- Max. temperature:-29℃ - 180℃
- The ISO regular Mounting Pad accepts direct mounting of pneumatic and electric actuators.
Application
By turning the handle 90 or 180 degrees, users can select which inlet and outlet ports are open, creating distinct flow patterns. For example, one position may allow one inlet to direct flow toward two outlets, while another position isolates the flow to a single path. These simple yet effective port designs help streamline piping systems, reduce the number of components, and ensure reliable control in industrial applications.
Why choose us?
Allows for flow to occur between any two ports as well as all three ports simultaneously in a T-Bore
1. You can direct flow to either of the 2 ports just like the L-Port, and you can have flow through all ports simultaneously.
2. Also called Mixing Valves because they are widely used to mix the flow coming from two sources.
3. It is compact and reliable, and has good sealing properties. It has also been widely used in vacuum systems.
4. The operation is convenient, the opening and closing is rapid, and the rotation is 90° from full opening to full closing, which is convenient for long-distance control.
5. The maintenance is convenient, the ball valve has a simple structure, and the sealing ring is generally movable, and the disassembly and replacement are relatively convenient.
