Pneumatic Tank Bottom Valve With ISO Mounting Pad Stainless Steel
Product Details:
| Place of Origin: | China |
| Brand Name: | CXDLV |
| Certification: | CE&ISO |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | negotiation |
| Packaging Details: | Suitable Plywood Cases according to different valves structure |
| Delivery Time: | 5~25 Work Days |
| Payment Terms: | T/T, Paypal, Western Union, D/A, L/C, D/P, MoneyGram |
| Supply Ability: | 500pcs/Mon |
|
Detail Information |
|||
| Body Material: | CF8,CF8M,WCB | Ball Material: | CF8,CF8M |
|---|---|---|---|
| Seat Material: | PTFE/PPL | Standard: | GB/ANSI |
| Design: | Full Port | Actuated: | Integral ISO 5211 Mounting Pad |
Product Description
Pneumatic Tank Bottom Valve With ISO Mounting Pad
Application
The tank bottom ball valve is used for pressure vessels and storage tanks of draining and discharging with the fully inclusive designed ball seat and compensation automatic type sealing . So it has advantage of high pressure, high temperature resistance, small torque, long life and other characteristics to meet CIP and SIP cleaning and sterilization. It is very suitable for the application in high cleanliness requirements in process systems such as pharmaceutical, food and beverage, dairy products, chemical industry etc..
Pneumatic tank bottom ball valve can configure a variety of different actuators, electric, pneumatic and manual are interchangeable.
Design Features
- Size:1"-4",DN25-DN100
- Material :304/CF8,316/CF8M
- Max. temperature:-29℃ - 150℃
- Operating torque is small
- The ISO regular Mounting Pad accepts direct mounting of pneumatic and electric actuators.Pneumatic Tank Bottom Valve With ISO Mounting Pad
Application
The valve is mainly used in industrial circulating water supply and drainage , urban water supply and drainage , high-rise buildings and hotels of pressurized water outlet of the pump , used to cut back water and the elimination of destructive water hammer , guarantee the safe operation of the pipe network . Designed to take full account of the environmental requirements , no vibration, no noise , smooth operation , ensure that hotels, residential quiet and has a power-saving functions.
Why choose us?
1. The fluid resistance is low, and the resistance coefficient is equal to the pipe lengthh.
2. The structure is simple, small in size and light in weight.
3. It is compact and reliable, and has good sealing properties. It has also been widely used in vacuum systems.
4. The operation is convenient, the opening and closing is rapid, and the rotation is 90° from full opening to full closing, which is convenient for long-distance control.
5. The maintenance is convenient, the ball valve has a simple structure, and the sealing ring is generally movable, and the disassembly and replacement are relatively convenient.
6. When fully open or fully closed, the sealing surface of the ball and the valve seat is isolated from the medium, and the medium does not cause erosion of the sealing surface of the valve.
7. Wide range of applications, from small to a few millimeters, up to a few meters, from high vacuum to high pressure can be applied.
