Manual Stainless Steel Globe Valve with Screw Action for Easy Operation

Manual Stainless Steel Globe Valve with Screw Action for Easy Operation
Manual Stainless Steel Globe Valve with Screw Action for Easy Operation

Large Image :  Manual Stainless Steel Globe Valve with Screw Action for Easy Operation

Product Details:
Place of Origin: China
Brand Name: CXDLV
Certification: ISO9001:2008 CE
Model Number: J41W
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiation
Delivery Time: 7-30 days
Payment Terms: L/C, T/T, Western Union
Detailed Product Description
Ball Material: CFM8/CF8/CF3M/CF3 Size: DN65~DN80
Standard: ANSI,GB Seal Material: PTFE
Working Temperature: Normal Temperature Disc: SUS304

High Pressure Full Bore Stainless Steel Globe Valve Good Sealing SUS304 Disc



Specifications



- Design Standard:GB/T2224-2005
- Inspection & Test: JB/T9092-1999
- Face To Face: GB/T12221-2005
- Pressure testing: GB/T13927-1992



 Application



  Globe valve are named for their spherical body shape with the two halves of the body being separated by an internal baffle.This has an opening that forms a seat onto which a movable plug can be screwed in to close (or shut) the valve.The plug is also called a disc or disk.In globe valve, the plug is connected to a stem which is operated by screw action using a handwheel in manual valves.Typically,automated globe valve use smooth stems rather than threaded and are opened and closed by an actuator assembly.

Manual Stainless Steel Globe Valve with Screw Action for Easy Operation 0

DN L D D1 D2 b Z-φd H D0
15 130 95 65 46 14 4-14 188 140
20 150 105 75 56 16 4-16 188 140
25 160 115 85 65 16 4-16 212 140
32 190 135 110 78 18 4-18 285 160
40 200 150 110 84 18 4-18 246 160
50 230 165 125 99 20 4-20 252 200
65 290 185 145 115 20 4-20 308 200
80 310 200 160 132 22 8-20 327 250
100 350 220 180 155 22 8-22 384 250
125 400 250 210 184 22 8-22 484 300
150 480 285 240 211 24 8-24 547 350
200 600 340 295 265 24 12-24 660 350



 Feature



The globe valve mainly serves to cut off the pipeline medium. Compared with the gate valve, the adjustment performance is better, the opening height is small, the closing time is short, the manufacturing and maintenance are convenient, the sealing surface is not easy to be worn and scratched, the sealing performance is good, and the service life is long; the valve body structure design of the shut-off valve is rather tortuous. Therefore, the flow resistance is large and the energy consumption is large; it is suitable for mediums such as steam and oil, and should not be used for mediums with large viscosity, with particles, easy to coke, and easy to precipitate. Medium and high pressure shut-off valves, large-diameter globe valves can be balanced structure, the extension of the shut-off valve - throttle valve, by changing the flow section to control the pressure and flow of the medium, except for the opening and closing parts using streamline cone type, other large Some are identical to the shutoff valve.



 Package&Delivery



Packing Details: We choose suitable wood cases according to different valves and arrange skilled workers to pack in case of bruise. Long term cooperated forwarder will book space, clear customs and transport for us without delay. There are three ways for transportation, by sea, by air and by train. We will arrange transportation according to customers' needs.

Delivery Details: according to the order, 7~60days



 FAQ



Q: Are you trading company or manufacturer ?

A: We are a factory.

Q: How long is your delivery time?

A: According to the order,7~60days.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
