ANSI 150LB Low Platform Stainless Steel Connetion T Type 3 Way Ball Valve Flange

ANSI 150LB Low Platform Stainless Steel Connetion T Type 3 Way Ball Valve Flange
ANSI 150LB Low Platform Stainless Steel Connetion T Type 3 Way Ball Valve Flange

Large Image :  ANSI 150LB Low Platform Stainless Steel Connetion T Type 3 Way Ball Valve Flange

Product Details:
Place of Origin: China
Brand Name: CXDLV
Certification: CE&ISO
Model Number: Q44/45F
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiation
Packaging Details: Suitable Plywood Cases according to different valves structure
Delivery Time: 5~25 Work Days
Payment Terms: T/T, Western Union, L/C, D/A, D/P, MoneyGram, Paypal
Supply Ability: 500pcs/Mon
Detailed Product Description
Connetion: Flange Seat: PTFE,RPTFE,POB
High Light:

ANSI 3 Way Ball Valve


3 Way Ball Valve Flange


150LB Ball Valve Flange

ANSI 150LB Low Platform Stainless Steel Connetion T Type 3 Way Ball Valveflange

XIDELONG Worm Gear Three Way Stainless Steel Flange Ball Valve
Worm Gear
1 Set
Applicable Standard
No. of Ways
3 Way
Port Size
4 inch
End Connection
Operating Pressure
0 to 1.6MPa
Water, Oil, Gas, Air
Body Material
Stainless Steel
Temp. of Media
-20°C to 180°C
Valve Ball
Stainless Steel
Sealing Material
1 Year (12 Months)


Three-way ball valve is available in T and L versions. The T-type enables three orthogonal pipes to communicate with each other and cut off the third channel to function as a split and merge. The L three-way ball valve type can only connect two pipes that are orthogonal to each other, and can not keep the third pipe connected to each other at the same time, only to distribute.




Pressure Size L L1 D D1 D2 Z-φd ISO5211
PN16 15 130 65 95 65 45 4-14 F5 4-φ6
20 160 80 105 75 55 4-14 F5-F7 4-φ8
25 180 90 115 85 68 4-14 F5-F7 4-φ8
32 200 100 135 100 78 4-18 F5-F7 4-φ8
40 220 110 145 110 88 4-18 F7-F10 4-φ10
50 240 120 160 125 102 4-18 F7-F10 4-φ10
65 260 130 180 145 122 4-18 F7-F10 4-φ10
80 280 140 195 160 138 8-18 F10-F12 4-φ12
100 320 160 215 180 158 8-18 F10-F12 4-φ12
125 280 190 245 210 188 8-18 F12-F14 4-φ16
150 440 220 280 240 212 8-23 F14-F16 4-φ16
200 550 275 335 295 268 12-23 F14-F16 4-φ16


Advantages of Ball Valve

  • With lowest flow resistance
  • It can realize quick opening and closing, and the opening and closing time of some structures is only 0.05~0.1s, so that it can be used in the automation system of the test stand. Quick open and close the valve when operating without impact.
  • In full open and full closed, the ball and seat of the sealing surface and media isolation,so high-speed through the valve medium will not cause the erosion of the sealing surface.
  • Compact structure,light weight,it can be considered for low-temperature medium system for the most reasonable valve structure.
  • Manufactured in different sizes providing flexibility in selection
  • Provide safe service under high pressure and high temperature conditions
  • Compared with other valves,they are controlled with less force.
