H74 Single Disc Swing Wafer Check Valve With Spring Stainless Steel ANSI 150LB

Certification
China Wenzhou Xidelong Valve Co. LTD certification
China Wenzhou Xidelong Valve Co. LTD certification
Xidelong is very much appreciated for the prompt assistance and also after sales service.

—— Mr Teo - Malaysia

“To me, Xidelong means: quality, realistic pricing, punctuality, partnership”

—— Mr Burzan - Argentina

I always feel in safe hands when I work with Xidelong.

—— Sebastian - Poland

We cooperated with Xidelong for some Government projects, the valves are well working and customer is satisfied

—— Mr Hengky - Indonesia

I'm Online Chat Now

H74 Single Disc Swing Wafer Check Valve With Spring Stainless Steel ANSI 150LB

H74 Single Disc Swing Wafer Check Valve With Spring Stainless Steel ANSI 150LB
H74 Single Disc Swing Wafer Check Valve With Spring Stainless Steel ANSI 150LB

Large Image :  H74 Single Disc Swing Wafer Check Valve With Spring Stainless Steel ANSI 150LB

Product Details:
Place of Origin: China
Brand Name: CXDLV
Certification: ISO9001:2008 CE
Model Number: H74
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiation
Delivery Time: 7-30 days
Payment Terms: L/C, T/T, Western Union
Detailed Product Description
Disc Material: CF8M/CF8/CF3/CF3M Bolt/Washer: CF8M/CF8/CF3/CF3M
Seal: Viton Temperature: -29℃~400℃
Medium: Water.Air.Oil Size: 1/1/2"~24"
High Light:

Single Disc Swing Wafer Check Valve

,

ANSI 150LB Wafer Check Valve

,

SS Spring Wafer Check Valve

      H74 Single Disc Swing Wafer Check Valve With Spring Stainless Steel ANSI 150LB



 Specifications

Applicable Standards:

-FACE TO FACE: AP16D/ANSE B16.10

-FLANGE DIMENSION: ANSI/DIN/JIS/JB

Size Range:
- 1/1/2"~24"

Pressure Rating:
- 125LB~600LB
Temperature Range:
- -29°C~180°C



 Application



     H74 clip single-valve check valve is an ultra-thin check valve, which has the advantages of simple structure, beautiful appearance, light weight and convenient installation. The thin check valve is mainly suitable for the water supply system, petroleum, chemical, metallurgical and other industrial sectors, which is most suitable for places with installation space restrictions.



H74 Single Disc Swing Wafer Check Valve With Spring Stainless Steel ANSI 150LB 0

SIZE B A L
1 1/2" 23 87 19
2" 30 104 19
2 1/2" 41 124 19
3" 54 136 19
4" 71 174 19
5" 92 197 19
6" 112 222 19
8" 155 279 28
10" 201 339 28
12" 240 409 38
14" 270 450 44
16" 311 514 48
18" 360 549 58
20" 410 606 64
24" 490 717 68


 Feature



1. The valve flap is closed quickly and the water hammer pressure is small;
2. Horizontal or vertical pipes can be used for easy installation;
3. Smooth flow path and low fluid resistance.



 Package&Delivery



Packing Details: We choose suitable wood cases according to different valves and arrange skilled workers to pack in case of bruise. Long term cooperated forwarder will book space, clear customs and transport for us without delay. There are three ways for transportation, by sea, by air and by train. We will arrange transportation according to customers' needs.

Delivery Details: according to the order, 7~60days



 FAQ



Q: Are you trading company or manufacturer ?

A: We are a factory.

Q: How long is your delivery time?

A: According to the order,7~60days.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.



 Application



     H74 clip single-valve check valve is an ultra-thin check valve, which has the advantages of simple structure, beautiful appearance, light weight and convenient installation. The thin check valve is mainly suitable for the water supply system, petroleum, chemical, metallurgical and other industrial sectors, which is most suitable for places with installation space restrictions.
