| MOQ: | 1pc |
| Price: | negotiation |
| Standard Packaging: | Suitable Plywood Cases according to different valves structure |
| Delivery Period: | 5~25 Work Days |
| Payment Method: | T/T, Paypal, Western Union, D/A, L/C, D/P, MoneyGram |
| Supply Capacity: | 500pcs/Mon |
2PC Stainless Steel Floating Ball Valve With Soft Sealing RF Flanged Type
Specifications
Suitable for :
- Oil
- Water
- Sewerage Industries
Applicable Standards:
- Design: GB/T12237-2008
- End Flange: HG/T20592-2009
- Face to Face: GB/T12221-2005
- Inspection Testing: GB/T13927
Size Range:
- DN15~DN200
Pressure Rating:
- GB PN16 PN25 PN40
Temperature Range:
-20°C~185°C
Ball valve, the opening and closing member (sphere) is driven by the valve stem and rotates around the axis of the ball valve. It can also be used for fluid regulation and control. The multi-way ball valve not only can flexibly control the confluence, splitting, and flow direction switching of the medium, but also can close any channel and connect the other two channels.
| PN(Mpa) | DN | L | D | D1 | D2 | T | f | N-φh | Q | Q1 | Q3 | Q2 | |
| 1.6 | 40 | 165 | 150 | 110 | 88 | 18 | 2 | 4-18 | 70 | 102 | 12 | 17 | |
| 50 | 203 | 165 | 125 | 102 | 18 | 2.5 | 4-18 | 70 | 102 | 12 | 17 | ||
| 65 | Contact us freely | ||||||||||||
| 80 | |||||||||||||
| 100 | |||||||||||||
| 125 | |||||||||||||
| 150 | |||||||||||||
| 200 | |||||||||||||
Application
CXDLV Ball valves, serving Multi-National end users in a wide range of applications in many industries which can be extensively used for marine,petroleum,chemical, metallurgical,electric power,architectural,agriculture field.
Advantage
1. Small fluid resistance: pneumatic ball valve is the smallest of the fluid resistance of all valve classification, even the reduced diameter pneumatic ball valve, its fluid resistance is quite small.
2. Stem seal is reliable: Since the valve stem only rotates and does not move up and down, the packing seal of the valve stem is not easy to break, and the sealing capacity increases with the increase of the medium pressure.
3. The sealing performance of the valve seat is good: the sealing ring made of elastic material such as PTFE is easy to seal, and the valve sealing ability of the pneumatic ball valve increases with the increase of the medium pressure.
Video
Video
Video
|
|
