Ultra Thin Swing Style Wafer Check Valve Carbon Steel WCB For Gas Oil

Ultra Thin Swing Style Wafer Check Valve Carbon Steel WCB For Gas Oil
Ultra Thin Swing Style Wafer Check Valve Carbon Steel WCB For Gas Oil

Large Image :  Ultra Thin Swing Style Wafer Check Valve Carbon Steel WCB For Gas Oil

Product Details:
Place of Origin: China
Brand Name: CXDLV
Certification: ISO9001:2008 CE
Model Number: H74
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiation
Delivery Time: 7-30 days
Payment Terms: L/C, T/T, Western Union
Detailed Product Description
Disc Material: CF8M/CF8/CF3/CF3M/WCB Temperature: -29℃~180℃
Medium: Water.Air.Oil Size: DN150~DN200
Pressure: PN10 O-RING: VITON
High Light:

wafer swing check valve

,

wafer non return valve

Ultra Thin Swing Style Wafer Check Valve Carbon Steel WCB For Gas Oil​



 Specifications

Applicable Standards:

- FACE TO FACE: AP16D/ANSE B16.10

- FLANGE DIMENSION: ANSI/DIN/JIS/JB

Size Range:
- DN40~DN600

Pressure Rating:
- PN10~PN40
Temperature Range:
- -29°C~180°C



Application



The single-piece swing check valve H74W/X is an ultra-thin check valve. It adopts short structure size and single valve design. The movement is sensitive, and the installation space is especially limited. The most suitable place. The utility model has the advantages of simple structure, beautiful appearance, light weight, convenient installation and the like. Compared with the traditional swing check valve, this series of stainless steel valves has No external leakage, can be installed in any position, good sealing performance, small linear vibration, low pressure drop and zero seat ring wear advantage of check.The single flap swing check valve is a disc type ultra-thin check valve.

Ultra Thin Swing Style Wafer Check Valve Carbon Steel WCB For Gas Oil 0



DN B A(NF) L
40 24 93 16
50 28 108 16
65 45 128 16
80 55 142 16
100 76 162 16
125 93 192 16
150 118 218 19
200 160 273 28
250 200 329 28
300 230 385 38
350 273 445 38
400 313 496 48
450 362 556 48
500 412 618 58
600 491 732 68



 Feature



1. For the connection of the clamp, the connection form of the valve and the two pipes directly through the flange is bolted together. The method has the advantages of simple and compact structure, short structure length, small volume, light weight, low cost, good universal interchangeability and low maintenance cost, but is not conducive to the maintenance of downstream equipment.
2. EPDM rubber is the most commonly used sealing material. Its ozone resistance and weather resistance are excellent. The heat-resistant working temperature can reach -40°C-135°C. After modification, it can be subdivided into wear-resistant. Corrosion-resistant, heat-resistant and ordinary EPDM, can meet a variety of media requirements. At the same time, the cost is low, cost-effective, and is widely used in various industries.
3. Long service life and good reliability.



 Why choose us?



       Wenzhou Xidelong Valve Co.,Ltd is a professional manufacturer and exporter that is concerned with the design, development and production of valve , with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.



        As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching the Middle East, Europe,Asia.



        Our well-equipped facilities and excellent quality control throughout all stages of production enables us to guarantee total customer satisfaction. Besides, we have received ISO9001 and CE.



 Package&Delivery



Packing Details: We choose suitable wood cases according to different valves and arrange skilled workers to pack in case of bruise. Long term cooperated forwarder will book space, clear customs and transport for us without delay. There are three ways for transportation, by sea, by air and by train. We will arrange transportation according to customers' needs.

Delivery Details: according to the order, 7~60days



 FAQ



Q: Are you trading company or manufacturer ?

A: We are a factory.

Q: How long is your delivery time?

A: According to the order,7~60days.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
