MOQ: | 1pc |
Price: | negotiation |
Standard Packaging: | Suitable Plywood Cases according to different valves structure |
Delivery Period: | 5~25 Work Days |
Payment Method: | T/T, Paypal, Western Union, D/A, L/C, D/P, MoneyGram |
Supply Capacity: | 500pcs/Mon |
DN150 6 Inch 2PC Trunnion Ball Valve CF8M Stainless Steel Split Body Price
Specifications
Overview
The trunnion ball valve is a form of quarter-turn valve which uses a hollow, perforated and fixed/supported ball to control flow through it.
A trunnion mounted valve means that the ball is constrained by bearings and is only allowed to rotate, the majority of the hydraulic load to be supported by the System constraints, resulting in low bearing pressure and no shaft fatigue. The line pressure drives the upstream seat against the stationary ball so that the line pressure forces the upstream seat onto the ball to cause it to seal.
The mechanical anchoring of the ball absorbs the thrust from the line pressure, preventing excess friction between the ball and seats, so even at full rated working pressure operating torque remains low. This is particularly advantageous when the ball valve is actuated because it reduces the size of the actuator and hence the overall costs of the valve actuation package.
Advantage
Trunnion mounted ball valve is an economical and high-performance quarter-turn valve. The quarter-turn operation is fast and reliable which makes this valve applicable to quick on-off operation and tight seal. This ball valve is widely used in pulp paper refinery, mining, chemical fiber, sewage and water treatment, sugar refining industry.
Body:
Separate body design, various materials are available.
Ball
The ball is trunnion mounted, which prevent seat damage and reduce seat ware dramatically comparing with floating ball valve.
The ball is precisely machined and mirror finished for bubble-tight shut off and less operating torque.
Full bore design minimizes the flow resistance and achieve better valve performance.
Seat:
With seats on both sides,the trunnion ball valve can handle flow in either direction with 0 leakage.
Seat is spring preloaded, which ensures self sealing adjustment when flow pressure changes to achieve 0 leakage.
Application
Ball valves can be used in a variety of applications and markets, such as transmission and storage, gas processing, industrial, and many more.that ball valves provide reliable leak protection which is especially beneficial in gas applications. Ball valves have low pressure drop and can open and close quickly.
A variety of construction materials, trim options and designs make these valves extremely versatile. Ball valves, such as RING-O subsea ball valves, are commonly utilized in subsea applications on manifolds that require long service life at high pressures. Ball valve also are used in cryogenic applications where compressed gas must be kept at a stable temperature in order to be moved efficiently.
Why Choose Xidelong?
Specializing:
We are specializing in manufacturing Ball Valve , Butterfly Valve , Gate Valve , Globe Valve , Check Valve , Sight Glass , Valve Accessories
Advantage:
1. Price: As we are the professional manufacture in valves and accessories, we ensure that the price offered must be very competitive compare with others.
2. Raw material inspection: All material test high quality, and keep in warehouse.
3. Workers: All workers training 3 months, skilled workers on production line.
Sample Order:
We will charge express fee only for old customers in generally, and for new customers we will charge 50% of the units cost and express fee mostly. (It can be discussed, we keep options always.)
Delivery Time:
We usually take 20days for official orders after received the prepayment, And Sample orders will be ready within 7days.
Quality Control:
We got very strict and complete quality system to ensure that each product will meet quality requirements as per clients, incoming quality control, final quality control, out-going quality control. Meanwhile, all of the products will be strictly inspected before delivery. "Quality First, Service First" that we are pursuing All the time.
Warranty Period:
18 months from the date we signed the contract or PI. Technical support for the whole life.
(In case of goods discrepancy to the order and drawings, the customers issues Reclamation Report concerning defective goods and attaches photo documents. customers shall consider either to make an additional delivery for replacement of defective goods, all expenses are covered by our company. Or the customers shall decide that we should compensate expenses for defective goods. Such compensation will cover all transport costs, custom duty costs, amount of paid goods.)
Payment Terms And Conditions:
1. TT Terms: The payment will be 30% of prepayment by direct bank remittance (T/T),remaining 70% before Shipment or the copy of BL send by us Via Fax or Email.
2. L/C Terms: Payment by L/C at sight and Unrestricted. (L/C must allow 30days minimum from the shipment date of presentation of documents for negotiation, all the clauses within L/C must be clear, concise and acceptable. Do not allow special clauses, terms and conditions.)
Competitive Price:
We provide competitive price, good quality and best service to reach the win-win goal.
Customization:
custom-made is acceptable.
